Building Production RAG Systems

1. Production RAG Architecture & Trust Domains

• RAG as Information Retrieval + Context Assembly + Model Generation
• "IR is solved enough to source. Your institution isn't."
• Defining trust domains: public, institutional, and restricted/instance-specific boundaries
• Treating the vector index as derived state vs. the source system of record
• Why search_everything() is a systemic anti-pattern

2. Metadata Schemas & Corpus Lifecycle

• Metadata as the primary schema of a RAG system; embeddings as auxiliary indexes
• Required metadata fields: document_id, version, tenant_id, classification, effective_date, nda_scope
• Document lineage, content hashes, and change detection
• Tombstone, deletion, retention, and re-indexing workflows without losing provenance

3. Document Parsing & Structure Extraction

• Multi-column layout analysis, reading-order extraction, and table preservation
• Semantic chunking vs. parent-child document strategies
• Sourcing parser capabilities: Docling, Marker, Tika, Unstructured, OCRmyPDF
• Lab standard focus: Standardizing ingestion on Docling

4. Representation Infrastructure & Reranking Engines

• Decoupling generation engines from representation servers
• Sourcing representation servers: Text Embeddings Inference (TEI), Infinity
• Two-stage retrieval mechanics: candidate retrieval vs. cross-encoder reranking (e.g., BGE-Reranker)

5. Open-Source Information Retrieval (IR) Engines

• Lexical sparse search (BM25) vs. dense vector similarity
• Sourcing search engines: OpenSearch, Elasticsearch, Vespa, Weaviate, Qdrant
• Algorithmic rank fusion: Reciprocal Rank Fusion (RRF) vs. weighted score normalization

6. In-Line Retrieval Evaluation

• Measuring retrieval performance before model generation
• Baseline evaluation metrics: Recall@k, Mean Reciprocal Rank (MRR), and Normalized Discounted Cumulative Gain (NDCG)
• Building small judgment sets to quantify retrieval precision shifts
• Lab 1: production-rag/ingest, metadata & retrieval
• Lab 1: Initialize the persistent production-rag/ monorepo
• Lab 1: Implement a Docling ingestion worker to parse multi-column financial and clinical PDFs containing nested tables into clean Markdown
• Lab 1: Attach explicit metadata schemas, generate version lineage hashes, and handle document deletion/tombstone events in the index
• Lab 1: Spin up OpenSearch and TEI services within the production-rag/ environment
• Lab 1: Construct a 30-query evaluation judgment set for the ingested corpus
• Lab 1: Benchmark search stages and measure metric shifts: BM25 -> Dense Vector -> Hybrid RRF -> Hybrid + Reranker

7. Identity & Fine-Grained Authorization (RBAC / ABAC / ReBAC)

• Enterprise SSO integration via OIDC, OAuth2, SAML, and Passkeys
• Sourcing identity engines: ZITADEL, Keycloak, Authentik, Ory, Authelia
• Sourcing policy engines: OpenFGA, Open Policy Agent (OPA), Cerbos, Casbin, Cedar
• Design Tension: Policy -> Search (pre-filtering via query injection) vs. Search -> Policy (post-filtering retrieved candidates)
• Injecting dynamic security pre-filters into vector query payloads

8. Corpus Trust, Poisoning & Retrieval Attacks

• Threats in RAG: direct vs. indirect prompt injection via retrieved documents
• Document poisoning, malicious metadata injection, and cross-tenant data exfiltration
• Separating retrieved untrusted data from trusted prompt instructions
• Least-privilege tool execution and sandbox boundaries
• Lab 2: production-rag/authz
• Lab 2: Configure an OpenFGA policy engine with nested relationships (User Alice -> Member -> Research Team -> Assigned -> Study X -> Permits -> Corpus Y)
• Lab 2: Intercept user tokens and inject runtime security metadata filters into OpenSearch queries
• Lab 2: Execute an indirect prompt injection attack through a poisoned PDF and implement prompt-instruction boundary defenses

9. Programmed vs. Model-Classified Routing

• Programmed routing: explicit endpoints, typed requests, known schemas, and API contracts
• Model-classified routing: natural language, LLM classifiers, structured schema outputs, and application permission validation
• When to use deterministic code vs. model classification
• Replacing heavy orchestration frameworks with thin, application-owned control

10. Structured Truth & External Web Extraction

• Querying structured databases: DuckDB, PostgreSQL, ClickHouse, Trino, Apache Drill
• Web extraction vs. metasearch: why web crawlers (Crawl4AI) beat metasearch aggregators for RAG
• Domain-specific APIs: HAPI FHIR, Medplum, Blaze FHIR
• Lab 3: production-rag/router
• Lab 3: Implement both routing strategies in production-rag/router (Programmed Branch vs Model-Classified Branch)
• Lab 3: Route structured metrics queries to DuckDB, institutional document queries to OpenSearch, and live web extraction requests to Crawl4AI
• Lab 3: Merge heterogeneous responses into a unified application data contract

11. Context Assembly & Prompt Engineering

• Context window token budgeting, trimming, and "lost-in-the-middle" re-ordering
• Preserving source span IDs and document lineage across context windows
• Structuring system prompts to enforce citation grounding and prevent post-hoc citation hallucination

12. Private Model Serving & Constrained Generation

• Sourcing GPU model serving engines: vLLM, SGLang, llama.cpp, Ollama, Hugging Face TGI
• Constrained generation: forcing structured JSON outputs using Outlines, Guidance, or grammars
• Output schema validation vs. generic LLM guardrail wrappers
• Lab 4: production-rag/context & model
• Lab 4: Deploy a local vLLM inference instance running an open-weights LLM
• Lab 4: Build a context assembly module in production-rag/context that orders snippets, manages token limits, and preserves citation source spans
• Lab 4: Force structured JSON output with precise citation spans using an Outlines constraint proxy

13. System Observability & Automated CI/CD Evaluation

• Sourcing evaluation engines: Arize Phoenix, Ragas, DeepEval, Promptfoo, Opik
• Separating retrieval metrics (Recall@k, NDCG) from generation metrics (Faithfulness, Answer Relevance)
• Full-stack distributed tracing with OpenTelemetry and SigNoz

14. Production Resilience & Failure Semantics

• Failure modes: handling outages in OpenSearch, TEI, rerankers, policy engines, and LLM servers
• Enforcing fail-closed behavior for security and policy service failures
• Implementing degraded execution modes (e.g., falling back to hybrid BM25/vector when the cross-encoder times out)
• Circuit breakers, bounded retries, rate limiting, and dead-letter queues
• Lab 5: production-rag/eval, telemetry & Chaos Testing
• Lab 5: Instrument the complete production-rag/ monorepo with OpenTelemetry and visualize traces in SigNoz
• Lab 5: Execute an automated test suite using Arize Phoenix / Ragas against a Golden Dataset to block regressions in CI/CD
• Lab 5: Capstone Chaos Exercise: Systematically kill components of the running stack and evaluate system response (TEI/Reranker, OpenFGA Policy Engine, vLLM)
